- Fast scanning — up to 72 ppm in color or monochrome, landscape
- Ultrasonic double-feed detection with advanced control
- Scanner Central Admin Suite
- Loaded with "intelligent" functions for more efficient scanning
- Energy Star Compliant
Specifications
Model
fi-6750S
Functional Specifications
Document Feeding Mode
Automatic document feeder (ADF) & Flatbed
Image Sensor Type
Charge coupled device (CCD) image sensor (x 2)
Output Resolution
Monochrome, Grayscale and Color
50 to 600 dpi, 1200 dpi(2)
(adjustable by 1 dpi increments)
Optical Resolution
600 dpi
Output Format
Color: 24-bit; Grayscale: 8-bit; Monochrome: 1-bit
AD Converter
1,024 levels (10-bit)
ADF Capacity
200 sheets (A4: 80 g/㎡ or 20 lb.) (Active loadable ADF)
Daily Duty Cycle
8,000 Pages
Document Size
ADF Minimum
A8 (52 mm x 74 mm or 2 in. x 3 in.)
ADF Maximum
A3 Portrait (297 mm x 420 mm or 11.7 in. x 16.5 in.),
Double letter (279.4 mm x 431.8 mm or 11 in. x 17 in.)
Flatbed
304.8 mm x 457.2 mm or 12 in. x 18 in.
Interface
USB2.0/USB1.1
Scanning speeds(1)
Letter/Landscape Mode
Simplex
Duplex
Monochrome, Grayscale & Color @ 200 dpi
72 ppm
-
Monochrome, Grayscale & Color @ 300 dpi
72 ppm
-
Flatbed
0.6 seconds (200 dpi), 0.7 seconds (300 dpi)
Letter/Portrait Mode
Simplex
Duplex
Monochrome, Grayscale & Color @ 200 dpi
55 ppm
-
Monochrome, Grayscale & Color @ 300 dpi
55 ppm
-
Flatbed
0.9 seconds (200 dpi), 1.1 seconds (300 dpi)
Physical Specifications
Power Requirements (auto-switching)
AC 100 to 240 V, 50 / 60 Hz
Power Consumption
Operating
130 W
Sleep Mode
Less than 3 W
Auto Standby (Off) Mode
Less than 0.5 W
Operating Environment
Temperature
5 °C to 35 °C (42 °F - 95 °F)
Relative Humidity
20 % to 80 % (non-condensing)
Dimensions (HxWxD)
342 mm x 690 mm x 500mm (13.5" x 27.2" x 19.7"
Weight
35 kg (77.2 lb.)
Reliability Specifications
Daily Duty Cycle
Up to 15,000 documents per day
Features
Automatic color detection,
content-based rotation, intelligent blank page deletion, background
saturation, advanced clarity, selectable background, onboard JPEG
compression, swivel ADF
OS Support
Windows® 10 (32-bit/64-bit), Windows®
8 / 8.1 (32-bit/64-bit), Windows® 7 (32-bit/64-bit), Windows Vista®
(32-bit/64-bit), Windows XP® (32-bit/64-bit), Windows Server® 2012
(64-bit), Windows Server® 2012 R2 (64-bit), Windows Server® 2008
(32-bit/64-bit), Windows Server® 2008 R2 (64-bit)
Bundled Software
PaperStream IP (TWAIN/ISIS)
Driver, Software Operation Panel, Error Recovery Guide, PaperStream
Capture, ScanSnap Manager for fi Series, ABBYY FineReader for ScanSnap,
Scanner Central Admin Agent
Options
2D Barcode for PapaerStream, Black Document Pad
Others
Multi-feed Detection
Yes, Ultrasonic double feed detection with Intelligent MultiFeed Function
Long paper scanning
3,048 mm (120 in.)
