- Powered by AMD Radeon R7 250 GPU
- Integrated with the first 2048MB GDDR5 memory and 128-bit memory interface
- OC Edition - Core Clock: 1100 MHz (Std 1050 MHz)
- Features Single-Link DVI-D / HDMI / D-Sub
- Support PCI Express 3.0 x8 bus interface
- System power supply requirement: 400W
Using high quality components on graphics cards is the key factor for having a long lasting, stable and reliable product. GIGABYTE is again setting a new standard by using Ferrite Core Chokes, Low RDS (on) MOSFET and Lower ESR Solid Capacitors, providing the stability and reliability from their high-end graphics solution. In addition, GIGABYTE Ultra Durable 2 Edition graphics cards now feature a sophisticated layout topology. This state-of-the-art power design from GIGABYTE delivers the ideal integration of thermal, electric characteristics, digital signals, power circuitry and optimum placement of components for enhanced graphics performance.
Ultra Cooling - Low RDS(on) MOSFET Design
Low Power Loss - Ferrite Core Choke Design
Longer Life - All-Solid Capacitor Design
GIGABYTE custom-designed 10 cm cooler
As opposed to the stereotype, GIGABYTE is able to maximize fan size to 10cm with the latest cooling design. With a 10cm fan, the card is virtually silent that its noise level runs much lower
Gold plated HDMI
Gold plated, durable large contact area connectors have been used for optimum signal transfer between connections
OC GURU ll
Brand-new instinctive user interface, easier to monitoring and adjusting all important settings. Users can set up MONITORING, GPU CLOCK, MEMORY CLOCK,FAN, OSD, ONLINE SUPPORT and update driver, BIOS directly.
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
| Chipset | Radeon R7 250 |
| Memory Clock | 4600 MHz |
| Process Technology | 28 nm |
| Memory Size | 2048 MB |
| Memory Bus | 128 bit |
| Core Clock | 1100 MHz (Std 1050 MHz) |
| Card Bus | PCI-E 3.0 |
| Memory Type | GDDR5 |
| DirectX | 11.2 |
| OpenGL | 4.2 |
| PCB Form | ATX |
| Digital max resolution | 4096 X 2160 |
| Analog max resolution | 2048 x 1536 |
| Multi-view | 2 |
| I/O | Single-link DVI-D*1 / HDMI*1 / D-Sub*1 |
| Card size | H=35 L=203 W=135 mm |
| Power requirement | 400W
|
