Supports New Intel® Core™ i7 processors Extreme Edition in LGA 2011-3 socket
-
Supports Quad Channel DDR4-3333(OC) Memory
-
USB 3.1: Delivering speeds up to 10Gb/s, USB 3.1 offers performance twice as fast as a regular USB 3.0 connection.
-
Turbo M.2: delivering next generation M.2 Gen3 x4 performance with transfer speeds up to 32 Gb/s
-
SATA Express + USB 3.1 + SATA 6Gb/s
-
Multi-GPU: NVIDIA Quad SLI & AMD Quad CrossFire Support
-
OC Engine: For More Flexible BCLK Adjustments
-
USB Steel Power: Super Stable 5V Power & Better Signal Transmission over USB
-
Intel® Gigabit LAN: Always connected with Intel® Gigabit LAN networking
-
Guard-Pro: Improved Protection and Power Efficiency
-
Military Class 4: Top Quality & Stability
-
OC Genie 4: Overclock in 1 Second
-
Click BIOS 4: Easily Fine-tune Your System
-
Command Center: Control & Customize Your PC Settings
-
Supports New Intel® Core™ i7 processors Extreme Edition in LGA 2011-3 socket
-
Supports Quad Channel DDR4-3333(OC) Memory
-
USB 3.1: Delivering speeds up to 10Gb/s, USB 3.1 offers performance twice as fast as a regular USB 3.0 connection.
-
Turbo M.2: delivering next generation M.2 Gen3 x4 performance with transfer speeds up to 32 Gb/s
-
SATA Express + USB 3.1 + SATA 6Gb/s
-
Multi-GPU: NVIDIA Quad SLI & AMD Quad CrossFire Support
-
OC Engine: For More Flexible BCLK Adjustments
-
USB Steel Power: Super Stable 5V Power & Better Signal Transmission over USB
-
Intel® Gigabit LAN: Always connected with Intel® Gigabit LAN networking
-
Guard-Pro: Improved Protection and Power Efficiency
-
Military Class 4: Top Quality & Stability
-
OC Genie 4: Overclock in 1 Second
-
Click BIOS 4: Easily Fine-tune Your System
-
Command Center: Control & Customize Your PC Settings
MSI USB 3.1 2X FASTER
USB 3.1 allows for speeds up to 10 Gbps, doubling the speed
compared to USB 3.0 and 20x faster than legacy USB 2.0. USB 3.1 is even
faster than SATAIII! Transferring your favorite games, music and movies
over USB has never been faster.
Feature
-
2X faster than USB 3.0
-
20x faster than USB 2.0
-
Up to 10Gbps data transfer bandwidth
-
Boost transfer rate between your PC and external storage devices
PUSH YOUR SSD
EVEN HARDER WITH TURBO M.2
Delivering speeds up to 32Gb/s using Gen3 x4, Turbo M.2 is more
than 5 times faster than a regular SATA III connection! Enjoy a blazing
fast system boot up and insanely fast loading of applications and games
with MSI motherboards.
Next generation M.2
Turbo M.2 is the successor to M.2 10 Gb/s, offering 3 times more
performance up to 32 Gb/s using Gen3 x4. M.2 is packed in a small form
factor and is compatible with 3 different sizes to fit most storage
solutions. All latest generation Intel® based MSI motherboards feature
Turbo M.2 storage.
Fast storage
with SATA Express
SATA Express introduces a new solution in high speed storage
through PCI-Express, providing more bandwidth for the latest generation
SSDs up to 10 Gb/s.
Optimized for
multiple graphics cards
With a large number of PCI-Express 3.0 x16 slots for every MSI
motherboard, you get to choose optimal placement for your graphics cards
for better fitting and airflow up to Quad SLI/CF. That way, you can
enjoy the best graphics at the highest framerate jumping off from your
screen when running a NVIDIA® SLI™ or AMD CrossFire™ setup.
OC Engine
Run into unstable situations when pushing your CPU to the limit?
This occurs because the internal clocks are linked through the 100 MHz
BCLK strap. Thanks to a integrated Clock Generator, MSI motherboards
support more flexible BCLK adjustments, from 100 / 125 / 167 MHz straps.
Using these straps prevents system crashing while overclocking on
the edge and opens doors to achieve the absolute maximum. The MSI X99
motherboards all come with the next generation Clock Generator offering
even lower jitter and power consumption resulting in even higher
stability under extreme conditions.
Military Class 4
Military Class 4 is the next step in high quality components. The
Dark Choke and Solid CAP will make sure that your PC runs more stable
under extreme gaming conditions.
SUPER FERRITE CHOKES
uper Ferrite Chokes use a Ferrite core that is Super-Permeable.
This allows the Super Ferrite Chokes to run at a 35 degree Celsius lower
temperature, have a 30% higher current capacity, a 20% improvement in
power efficiency and better overclocking power stability.
SOLID CAP
With their aluminum core design and Japanese made quality, Solid
CAPs are made for high-end design motherboard. Not only do Solid CAPs
could provide lower Equivalent Series Resistance (ESR), but also work
firmly for over-10-year.
-
Circuit Protection
Carefully selected materials, multiple PCB layers and shielding
result in the best circuit protection for our motherboards.
-
-
ECO Power
With MSI ECO Center you can physically cut the power to unused chips to save up to 19% power usage.
-
Humidity Protection
10% Reduction in moisture absorption helps prevent "Conductive
Anodic Filament". Untreated PCB's can have 10x higher failure rate. -
High Temperature Protection
All key components used in MSI motherboards have all passed
military testing ensuring stable operation in the harshest environments. -
ESD Protection
Each and every I/O port is protected against the hazards of Electro Static Discharge. -
EMI Protection
All MSI motherboards comply with stringent American FCC regulations and reduce the impact of Electromagnetic Interference.
INTEL® GIGABIT LAN
Always connected with Intel® Gigabit LAN networking. The latest MSI
X99 motherboards come equipped with the high quality network solution
from Intel®. Optimized for multimedia and gaming use to deliver a stable
and fast network connection.
ECO Power
ECO Power helps users to manage their hardware and power usage.
Save up to 19% power consumption by completely disabling unnecessary
hardware. ECO Power not only lowers the power consumption but also
avoids short circuiting and signal noise.
|
DEVICE |
ON (W) |
OFF (W) |
SAVE WATT |
|
USB 3.0 |
65.5 |
64.0 |
1.5 |
|
USB 3.0 |
65.5 |
63.8 |
1.7 |
|
USB 3.0 |
65.5 |
64.1 |
1.4 |
|
Wi-Fi |
65.5 |
63.8 |
1.7 |
|
M.2 |
65.5 |
62.2 |
3.3 |
|
CPUFAN* |
65.5 |
64.8 |
0.7 |
|
SYSFAN1* |
65.5 |
64.8 |
0.7 |
|
SYSFAN2* |
65.5 |
64.8 |
0.7 |
|
SYSFAN3* |
65.5 |
64.8 |
0.7 |
|
TOTAL |
65.5 |
53.1 |
12.4 |
USB
Rear I/O USB
19% save
SATA
* Power saving measurements might be different among different models.
Circuit Protection
With specially designed circuit protection, the MSI motherboard
protects the CPU against overheating and USB devices from short
circuiting.
Power Supply
USB
CPU
USB
USB STEEL POWER
Are your USB Bitcoin ASICs drawing too much USB power resulting in
losing bitcoins? USB Steel Power offers a stable 5 volt to all USB ports
via an extra PWM, optimizing all USB ports so that you’ll never have to
worry about any Bitcoin loss.
USB 5V PWM
Rear I/O USB
Stable 5V
Stable 5V
Front USB
connectors
POWER SUPPLY
Stable 5V
(12V)
USB 3.0
SMART UTILITIES
The MSI Smart Utilities application helps to easily setup,
configure and boost your systems’ performance and more through Intel®
key technologies:
*This feature only works on platform/model that supports Intel® Smart Response technology.
OC Genie 4
With the one-second overclocking option OC Genie we're giving you
even more performance. Just hit the button and your PC gets another
adrenalin shot straight away. Give your system an awesome performance
boost with ease.
CLICK BIOS 4
The MSI Click BIOS 4 is the latest UEFI BIOS with optimizations
for Windows 8. Not only that it also reacts faster, runs smoother and
has better mouse support. And this all comes with many cool features.
Click on the button on the right to visit our dedicated BIOS page and
learn more.
Click here to go to
UEFI BIOS PAGE
for more information
Software
COMMAND CENTER
MSI's Command Center software is a very powerful tool to push your
motherboard to the max. With a very intuitive touch ready interface,
Command Center allows users to tune settings to increase system
stability, maximize overclocking performance and adjust cooling
features.
LIVE UPDATE 6
MSI Live Update is renewed! Our popular software automatically
downloads and installs the latest drivers, BIOS and software. Rest
assured while your system is always configured using the latest software
so you get the maximum performance and stability.
UNLIMITED RAMDISK
MSI Command Center integrates an unlimited RAMdisk. With a RAMdisk
you can create a virtual drive from your system memory enabling speeds
20x faster than a modern SSD.
-
Speed up system performance
-
Load complete game images
-
Speed up games, apps and browser
ECO CENTER
Save the planet, lower your electrical bill. ECO Center lets you
disable unused chips and functions used on your motherboard. By cutting
off the power entirely, your motherboard will run more efficient, up to
19%!
FAST BOOT
No more seamless waiting for your O/S to be loaded! MSI Fast Boot
helps to make your system boot lightning fast. MSI Fast Boot also
features a GO2BIOS button. Simply click it to restart your PC and go
straight to the system BIOS.
- The specifications may differ from areas and we keep the right to
change without notice. Please check the specific specification with your
local dealers.
- The color of the product might be affected by photography and the
monitor's setting, which might be different from the real product.
-
