• 450Mbps Wireless speed and Gigabit Ethernet ports are ideal for multiple HD video streaming
• Multi-functional USB 2.0 port - Easily share a printer locally and files & media with networked devices or remotely via FTP server
• Wireless security encryption easily at a push of WPS Button

450Mbps Wireless N Gigabit Router TL-WR1043ND

• 450Mbps Wireless speed and Gigabit Ethernet ports are ideal for multiple HD video streaming
• Multi-functional USB 2.0 port - Easily share a printer locally and files & media with networked devices or remotely via FTP server
• Wireless security encryption easily at a push of WPS Button

Wireless Speed Up To 450Mbps 2.4GHz Set To Maximum

With wireless speeds of up to 450Mbps, the maximum speed available on a 2.4GHz single band, you can enjoy HD video streaming and online gaming with an even more fluid experience than 300Mbps and 150Mbps.

2.4GHz
450Mbps

300Mbps

150Mbps

HD Vidieo StreamingOnline GamingOnline Chatting

Fully extended coverage
3*5dBi antennas

3 external 5dBi antennas combined with higher quality antenna technology provide users with larger wireless coverage and stronger wireless signal intensity from anywhere in your large home or office.

Blazing Wired Speeds
5 Gigabit Ports + 800Mbps Hardware NAT

With 5 built-in gigabit ports and a Hardware NAT function, the wireless router provides powerful data processing capabilities. Its NAT WAN to LAN throughput can achieve up to 800Mbps+ allowing users to unleash the full potential of their networks.

NAT throughput

Easy for Sharing
Multi-functional USB Port

Using the TL-WR1043’s multi-functional USB ports, users can share printers, files and media either throughout the network at home with several different computers or even away. Using the device’s ftp server functions so that you never have to part with your files.

Printer SharingStorage SharingFTP ServerMedia Server

HARDWARE FEATURES
Interface 4 10/100/1000Mbps LAN Ports
1 10/100/1000Mbps WAN Port
1 USB 2.0 Port
Button WPS/Reset Button
Power Button
Wi-Fi Button
Antenna 5dBi*3 Detachable Omni Directional (RP-SMA)
External Power Supply 12VDC / 1.5A
Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Dimensions ( W x D x H ) 8.9 x 5.6 x 1.2in. (225 x 141 x 30mm)
WIRELESS FEATURES
Frequency 2.4-2.4835GHz
Signal Rate 11n: Up to 450Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Reception Sensitivity 270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Transmit Power CE:
<20dBm(2.4GHz)
FCC:
<30dBm
Wireless Functions Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
Wireless Security 64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK
SOFTWARE FEATURES
Quality of Service WMM, Bandwidth Control
WAN Type Dynamic IP/Static IP/PPPoE/
PPTP(Dual Access)/L2TP(Dual Access)/BigPond
Management Access Control
Local Management
Remote Management
DHCP Server, Client, DHCP Client List,
Address Reservation
Port Forwarding Virtual Server,Port Triggering, UPnP, DMZ
Dynamic DNS DynDns, Comexe, NO-IP
VPN Pass-Through PPTP, L2TP, IPSec (ESP Head)
Access Control Parental Control, Local Management Control, Host List, Access Schedule, Rule Management
Firewall Security DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding
Guest Network 2.4GHz Guest Network×1
OTHERS
Certification CE, FCC, RoHS
Package Contents TL-WR1043ND
3 detachable Omni directional antennas
Power supply unit
Resource CD
Ethernet Cable
Quick Installation Guide
System Requirements Microsoft® Windows® 8/7/Vista/XP/2000, MAC® OS, NetWare®, UNIX® or Linux.
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
